Description
Product Code: CP7782-6 + 18206
- High efficiency motor which is also economical, with a durable reinforced clutch mechanism
- Durable impact wrench with great power for the toughest jobs on heavy vehicles
- Comes with a free socket set - sizes 27mm, 30mm, 32mm, 33mm
- The socket set supplied may differ from the one shown in the picture
Features:
- 1” Straight impact wrench with 6” extended anvil
- 1920 ft.lbs - 2600 Nm of maximum torque in reverse
- Pinless closed reinforced rocking dog impact mechanism
- Dual socket retention, hole and friction ring
- Ergonomic side handle
- Full teasing trigger
- Regulator with integrated forward/reverse with 3-position power settings in both directions
Actual Air Consumption: 19.2 l/s Air Inlet Thread Size: 1/2” Avg. Air Consumption: 4.8 l/s Blows Per Minute: 500 Bolt Size: M32mm Clutch Type: Pinless closed rocking dog Free Speed: 5200rpm Handle Type: D-Handle Inside Trigger Length: 520mm Maximum Torque (Reverse): 2600 Nm Min. Hose Size: 13mm Net Weight: 11.6kg Power/Weight Ratio: 224.1 Nm/kg Socket Retainer: Dual (hole + friction) Sound Power: 111 db(A) Sound Pressure: 100 db(A) Square Drive: 1” Vibration: 7.8 m/s² Vibration Uncertainty (K): 1.8 m/s² Vibration-ISO: ISO-28927-2 Working Torque Range (fwd): 500 - 2000 Nm
Product Code: OM18206
Effortless air operation will greatly reduce operator fatigue and speed up the efficiency of garage work.
A compact yet powerful Air Turbo Motor is equipped to raise the load to the desired height efficiently, effortlessly and safely.
Built-in bypass device protects hydraulic system from overpumping damage.
Versatile quick connector design provides for easy removal of the air hose from the air motor, allowing compact storage or remote operation.
With chrome-plated rams and equipped with external return springs.
Closed Height: 247mm Hydraulic Lift: 150mm Extension Screw: 85mm Maximum Height: 482mm Weight: 16.8kg
